The "Giornate di Studio SPARX e
Applicazioni" will be held at the Frascati
National Laboratories on 9-10 May 2005.
The aim of the Workshop is to inform the Italian
Scientific Community on the present FEL activities
at Frascati and, on the other hand, to stimulate a
discussion on possible applications of soft X-ray
radiation of FEL in the fields of materials,
biology, micro and nano technologies and
fundamental phenomena in phisics and chemistry.
Such applications will be grouped on the basis of
the main radiation properties: temporal structure,
coherence, high intensity and polarization.
Temporal profile of the
radiation generated by the FEL source The specific
example shown in fig. 1.c corresponds to a
simulation in time-dependent mode at 5 nm and 1.4
GeV of beam energy. (Preliminary
Simulations of the SPARX FEL, L. Giannessi)
The following table shows the
summary of the main radiation properties:
|
Wavelength
(nm)
|
3
|
5
|
10
|
15
|
15-seeded*
|
|
Pulse
Energy (mJ)
|
1
|
1.9
|
1.7
|
2
|
0.7
|
|
Peak
Power (GW)
|
4
|
7
|
5
|
9
|
20
|
|
Peak
Power Dens. (GW/cm2)
|
4 104
|
7 104
|
5 104
|
6 104
|
1 105
|
|
Beam
size @ saturation (r.m.s. μm)
|
40
|
40
|
50
|
50
|
50
|
|
Bandwidth
(%)
|
0.15
|
0.22
|
0.3
|
0.4
|
0.04
|
|
1st
order coherence length (μm)
|
0.7
|
0.9
|
1.5
|
2
|
10
|
|
Pulse
length (r.m.s. fs)
|
100
|
120
|
130
|
130
|
30
|
|
Flux
(Phot./s/0.1%bw)
|
4 1025
|
91025
|
1.5 1026
|
2 1026
|
4 1026**
|
|
Brightness
(Phot/s/0.1%bw/(mm-mrad)2)
|
3 1030
|
8 1030
|
7 1030
|
1 1031
|
2 1031**
|
|
Shot
to Shot power fluctuations (%)
|
12
|
14
|
16
|
18
|
-
|
* Seed with Gaussian profile,
rms length of 20 fs. The seed energy is 2.7 nJ,
corresponding to a peak power of 50 kW.
** Flux (Phot./s/0.01%bw), Brightness (Phot/s/0.01%bw/(mm-mrad)2)
Participants are invited to
register via web using the online Registration
Form.
Participation foreseen is 50-70 people.
A registration fee of 50,00 Euros, as contribution to the Workshop organization, must be paid cash at the Registration Desk (no
advance payment, no checks, no credit cards).
DEADLINES
REGISTRATION:
15 April 2005
HOTEL
RESERVATION:
15
April 2005
